Products

Epson offers several types of products for different printing applications.

S Series

PrecisionCore
The Epson S Series is a lineup of printheads focused on high productivity, high image quality, and head expandability.
Because these printheads are small, you can align a number of them within a limited space. This makes the printer much more compact.

Product information

S3200 series S800 series
S3200 series S800 series
Ink type Aqueous, UV/ Eco Solvent Aqueous, UV/ Eco Solvent
Type PrecisionCore MicroTFP printhead PrecisionCore MicroTFP printhead
Width × Depth × Height 150.4 × 30.0 × 52.0 mm 58.1 × 8.3 × 33.8 mm
Number of nozzle 3200 (Net: 2840) 800
Nozzle Resolution 300 npi/row 600 npi/2 rows 300 npi/row 600 npi/2 rows
Max. number of colour inks 2 colours 1 colour
Effective print width 120.2 mm (4.73 inches) 33.8 mm (1.33inches)
Ink recirculation Yes (Common channel recirculation) Aqueous: Not available
UV/ Eco Solvent: Common channel recirculation
Internal heater Not available Not available
Download Spec Sheet

I Series

PrecisionCore
The Epson I Series printheads are focused on high-quality printing. They have a compact shape and can be accurately aligned across four colors.

Product information

I3200(4) series I1600 series I3200(8) series
I3200 series I1600 series I3200 series
Ink type Aqueous, UV/ Eco Solvent Aqueous, UV/ Eco Solvent Aqueous
Type PrecisionCore MicroTFP printhead PrecisionCore MicroTFP printhead PrecisionCore MicroTFP printhead
Width × Depth × Height 69.1 × 59.5 × 35.6 mm 69.1 × 59.5 × 35.6 mm 69.1 × 59.5 × 36.7 mm
Number of nozzle 3200 1600 3200
Nozzle Resolution 300 npi/row 600 npi/2 rows 300 npi/row 600 npi/2 rows 300 npi/row 600 npi/2 rows
1200 npi/4 rows
Max. number of colour inks 4 colours 4 colours 8 colours
Effective print width 33.8 mm (1.33 inches) 33.8 mm (1.33 inches) 33.8 mm (1.33 inches)
Ink recirculation Not available Not available Not available
Internal heater Not available Not available Not available
Download Spec Sheet

F Series / L Series

Epson's F Series and L Series printheads are MACH type printheads. They feature powerful actuating and make it possible to use up to eight colors in one printhead.

Product information

L1440 F1440
L1440 F1440
Ink type UV/Eco Solvent/Aqueous Aqueous
Type MACH
(Multi Layer ACtuator Head)
MACH
(Multi Layer ACtuator Head)
Width × Depth × Height 60.4 × 46.9 × 71.1 mm 106.0 × 49.7 × 41.7 mm
Number of nozzle 1440 1440
Nozzle Resolution 180 npi/row 360 npi/2 rows 180 npi/row 360 npi/2 rows
Max. number of colour inks 8 colours 8 colours
Effective print width 25.4 mm (1 inch) 25.4 mm (1 inch)
Ink recirculation Not available Not available
Internal heater Not available Not available
Download Spec Sheet

Product specifications and descriptions are subject to change without notice.
